Premium Fanless Case for Intel® NUC 13 Pro (Arena Canyon)
Blending advanced passive cooling engineering and modern design to create a premium, silent and compact case for Intel® NUC 13 Pro (Arena Canyon). The perfect choice for home, office, HTPCs & audiophile environments.
Small but Powerful Supports Intel® NUC 13 Pro (Arena Canyon) with up to Intel® Core™ i7-1370P Processor and 4K displays or one 8K display outputs, making it ideal for digital signage applications or where multiple displays are required.
Advanced Performance Bi-symmetrical extruded fins on either side of the case maximise the surface area of the exterior for increased heat dissipation. Coupled with internally hi-efficient passive thermal module and 8mm heat pipes to ensure the Thermal Design Point (TDP) is met, with the case supporting the Intel® NUC 13 Pro up to 40W TDP.
Easy Installation Easily adjustable thermal module with two 8mm copper heat pipes to transfer the heat from the CPU. Superbly engineered for maximum efficiency and ease of use.
True Silent Experience Fanless CPU design eliminates the need for noisy mechanical fans so that true silence can be achieved. Paired with the use of Solid State Drives, one can truly immerse themselves in the experience of soundless acoustics.
Supports up to Four 4K Displays The Maxwell AC Pro case provides connector opening for dual HDMI 2.1 and dual Thunderbolt™ 4 from the Intel® NUC 13 Pro for connectivity of four 4K displays. Perfect for an array of business applications such as security and digital signage.
Wide Application Capabilities ldeal for home and business applications from digital signage to home-theatre setups and more.
Perfect for Casual Gaming The Maxwell AC Pro is designed for the NUC 13 Pro with Intel® 13th generation mobile processor up to Core™ i7 with integrated Intel® Iris® Xe Graphics. So play without fan noise so you can focus on your gaming experience!
Compact in Size 3.6L
Express Your Branding & Identity Optional bespoke engraving and colouring solutions to highlight and differentiate your fanless system solution. Requires a minimum order quantity - please talk to our Team about the different options available.
Perfect for your Build Optional hi-quality external antenna (A-ATN01-BK) and corresponding pigtail (A-ATC01-150GR) to connect the antenna to the Wi-fi connector. Perfect additions for your fanless Intel NUC build should a wireless connection be required.
The Intel® NUC 13 Pro (Arena Canyon) is available as a Mini-PC, Kit or Board models. For Board only models, there are optional compatible external power adapters available: 120W, 19V (AK-PD120-04M) for the Core i7 and i5 models, and 90W, 19V (AK-PD090-01M) for the Core i3 model.
Kotelo
Small Form Factor (SFF)
Malli
PC
Tuotteen väri
musta
Tuetut emolevyt
UCFF
3,25":n laitepaikkojen lukumäärä
0
5,25":n laitepaikkojen lukumäärä
0
Materiaali
Alumiini, Kupari
2,5":n laitepaikkoja
1
Jäähdytyslevy sisältyy
Kyllä
Päällä/pois-painike
Kyllä
LED-merkkivalot
HDD, Teho
Kaapelilukkopaikka
Kyllä
Kaapelilukon aukkotyyppi
Kensington
Virtalähde mukana
Ei
USB 3.2 (3.1 sukupolvi 1) A-tyypin porttien määrä
2
USB 3.2 Gen 2 (3.1 Gen 2) C-tyypin porttien määrä
0
USB 3.2 Gen 2 (3.1 Gen 2) A-tyypin porttien määrä
0
HDMI-porttien lukumäärä
2
Äänen sisääntulo
Ei
Äänen ulostulo
Ei
Sarjaporttien määrä
2
Sisäänrakennettu näyttö
Ei
Tuetut HDD-koot
2.5"
SSD-malli
2.5"
Tuotteen leveys
218,5 mm
Tuotteen syvyys
206 mm
Tuotteen korkeus
80,3 mm
LED-ohjain
Ei
Löydämme tuotteen järjestelmästämme helposti seuraavalla tuotenumerolla
SKU:
A-NUC94-M1B
